Tension strap HH70 740mm x 70mm x 3mm Steel

SKU EUR-954098
£25.50
In stock
1
Product Details

DATA SHEET The tension straps are shackles for absorbing tensile forces and tensile and shearing forces developed for modern timber construction.

Advantages

  • Many different areas of use
  • For installation in wood and concrete
  • Very high shear load-bearing capacity thanks to a new fixing concept
  • Fewer connectors required

Instructions for use

Anchoring in wood is carried out using 5 x 120 mm countersunk-head screws at an angle of 45°. A non-positive connection is created between the screw head and draw shackle thanks to the specifically designed holes, which can also be used as screw guides. The HH70 tension strap also has two holes (Ø 5 mm) which are provided for a 90° screw connection

ETA Approval: ETA-19/0020

Object of approval:

Three-dimensional nailing plate (hold-downs for timber-to-timber or timber-to-concrete or steel connections

DATA SHEET
